BEARING-SAFE™ Vibration Monitoring System

Overview of the BEARING-SAFE™
Monitoring excess vibration in rotating equipment is key to early identification of possible asset issues and the BEARING-SAFE™ is the perfect instrument for this job. Vibration monitoring uses accelerometers to measure changes in amplitude, frequency, and intensity of forces that damage rotating equipment. Studying vibration measurements allows the discovery of imbalance, looseness, misalignment, or bearing wear in equipment prior to failure. Regular monitoring can predict future failure and avoid costly down time.
BEARING-SAFE™ Applications
For monitoring bearings on
• Marine stern tubes
• Marine alternators
• Sea water pumps
• Hydro-electric plants
• Wind turbines
• Rail axle bearings and more
More bearing maintenance uses
• Axle-box breakdowns
• Helicopter gearboxes
• Automobile bearings
• Water pumps
• Air-conditioning units and more
The BEARING-SAFE™ Kit includes
• BEARING-SAFE™ unit
• Hard hat compatible headphones
• Full operating instructions
• Magnetic corrosion proof sensor
• Genuine Leather Case
• Sensor: 1.5m cable and magnetic clamp for hands-free use
BEARING-SAFE™ features
• BEARING -SAFE measures (acceleration,velocity and displacement at 11 different frequencies for 32hz to 16Khz.
• Features: Large graphic display
• Memory for 1000 readings
• Acceleration measurement g
• Velocity measurementm m/s
• Displacement measurement mm
• Unit Dimensions: 210 x 130 x 55mm
• Unit Weight: 540g including batteries and leather case
• Battery Life: 20 hours nominal with 4 x AA batteries
• Carry Case Dimensions: 450 x 370 x 100mm
• Sensor Dimensions: 95 x 60 x 45mm
• Temperature Range: -10˚C to +50˚C
• Total operational weight: 650g
• Shipping Weight: 1.1Kg
Accreditations
American Bureau of Shipping Classification Society Manufacturing Process Approval
ISO 9001:2015 Certificate Number 14124458
NATO Stock Number 6635-99-883-3612
NCAGE Number U0B22
IIMS Corporate Membership Number C508
